Triax 5 x 24  Multiswitch

Connect a Quattro LNB to a 60cm dish pointed at Astra 2 ( 28.2 east ) run 4 cables from the Quattro LNB to this Multiswitch, You can also connect a Freeview UHF aerial to this Multiswitch, with 24 outputs you have the opportunity to connect up to 24 satellite receivers or Combo Satellite / Terrestrial receivers. All receivers will have independent viewing.


Specifications:
Frequency Range               47-2150
Inputs                        4SAT + 1TERR
Throug Outputs                4SAT + 1TERR
Multiswitch Outputs           24
Connectors                    F
Trunk loss  Terr 47-862       4db
Sat 950-2150      4db
Tap    loss  Terr 47-862      14db
Sat 950-2150      14db
Lev Adj       Terr 47-862     12db
Range         Sat 950-2150    12db
ISOLATION (d)
Terr to Sat db    30
Sat to Terr db    30
Cross PolarH/V    28
Out - OutTerr     30
Out -Out Sat      30
RETURN LOSS
TERR input+output 47-862MHz       12db
SAT input + output 950-2150MHz    12db
Output levels SAT  (IMA3 35db)    95dBuv
ERR (IMA3 60db)    85dBuv
Input levelsSAT  (IMA3 35db)      121dBuv
TERR (IMA3 60db)      111dBuv
Switching commands 13V,18V, 13V/22kHz
18V/22kHz
Switching Voltage 15+/- 1V
Terr.Current 160mA
Max Current Each Port <250mA

Buy your Triax 5 x 24 Multiswitch from Satellite TV Shop, your free UK delivery store.
